Antelope Discrete 4 Pro Synergy Core

Thunderbolt/USB Audio Interface 14×20 Thunderbolt 3 & USB 2.0 audio interface with integrated real-time effects Synergy Core onboard platform with 2x DSP and 1x FPGA chip AD/DA conversion: up to 24Bit / 192kHz Up to 130dB dynamic range 4 Discrete 6-transistor preamps ON: -128dBu (A-weighted) Dynamic range: -122dB (A-weighted) THD: -116dB Max gain: 65dB Phantom power: 48V 37 Analogue modelled SC effects 64Bit Acoustically Focused Clocking (AFC) technology Latency <1ms for real-time monitoring with SC effects Digitally expandable via ADAT (8 channels) and via S/PDIF (2 channels) Dimensions (W x H x D): 261 x 44 x 208 mm Weight: 1.7 kg Incl. USB A/B cable and power supply unit Note: Thunderbolt cable not included in the scope of delivery Connections: 2 Combo inputs Mic/Line: XLR/jack 2 Combo inputs Mic/Line/Hi-Z: XLR/jack 4 DC-coupled line outputs: 6.3 mm jack 1 Monitor output L/R: 6.3 mm jack 4 Stereo headphone outputs: 6.3 mm jack 1 ADAT I/O (8 channels) 1 S/PDIF I/O (2 channels) 2 Word clock outputs Thunderbolt 3 USB 2.0 Type-B 30 30-Day Money-Back Guarantee 3 3-Year Thomann Warranty Available since May 2022 Item number 543058 Sales Unit 1 piece(s) Recording / Playback Channels 24X24 Number of Mic Inputs 4 Number of Line Inputs 4 Number of Line Outs 4 Headphone Outs 4 Phantom power Yes Number of S/PDIF Connectors 1 Number of ADAT Connectors 1 Numer of AES/EBU Connectors 0 Number of MADI Connectors 0 Ethernet 0 Other Connectors Thunderbolt 3 MIDI interface No Word Clock 2xOut Max. sample rate (kHz) 192 kHz Max. resolution in bit 24 bit USB Bus-Powered No Incl. power supply Yes USB Version 2.0 Width in mm 261 mm Depth in mm 208 mm Height in mm 44 mm Connection Format USB port Type B Show more
